JAMMA pinout stickers

[eurotronic]

Hi guys,
i designed a couple of decals to stick on the jamma connector.
Though this can interest some of you.

It look like this:



Here is the file:
JAMMA pinout decals for connector
Red numbers and letters go to PCB edge.




[Belike]

Very useful stuff, thanks for the link.

[Etienne MacGyver]

Very useful stuff, thanks for the link.

what a timing

Very cool !, thanks eurotronic!

ps if you want that i host the file, read your PM

[kroustibat]

great addition thanks !

[Belike]

I couldn't download it:
"The file you are trying to access is temporarily unavailable. Please try again later."

[Zorg]

permission asked to add it to vectorlib. in the sticker section.

can I ??

[eurotronic]

sure, no problemo.

[Etienne MacGyver]

I couldn't download it:
"The file you are trying to access is temporarily unavailable. Please try again later."

Try the link again

[Q*ris]

I was planning to do a T-shirt design with a Jamma pinout but your sticker idea is MUCH more useful!
Thanks for sharing!

[Belike]

I couldn't download it:
"The file you are trying to access is temporarily unavailable. Please try again later."

Try the link again

Much better now, thanks.
Can you adjust it to the correct size?

[Etienne MacGyver]

dimentions please
(dont have a jamma connector here...)

[DarthNuno]

I still have some Jamma loom with japanese (or chinese) indication on it... your sticker will be very useful, thanks for sharing it



[level42]

Yep...very handy.

[Belike]

dimentions please
(dont have a jamma connector here...)

That "stickin''' part is aprox. 11,8X1,5 cm.

[Etienne MacGyver]

click me....

Later i might retype it, then the filesize is smaller
