Author Topic: PAC MAN - Scratch Built Replica  (Read 59019 times)
scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« on: November 25, 2008, 03:21:59 PM »





HI guys,

I'm here with a new project:

PAC MAN - Scratch Built Replica

After Galaga cab: http://www.dragonslairfans.com/smfor/index.php?topic=402.0

 it's time for another Namco's classic arcade.

My idea was to build a Nintendo Donkey Kong cab from scratch.... but to much problems with pieces (coin door, bezel, etc....) these are the three cab that I would, so

....it's PAC TIME  pacman Ghost

already found pieces:




original 1980 control panel e coin door (need restorations) Space Ace Space Ace:



so... i'm almost ready, I need arts from Twobits and Marquee (already in custums here in Italy) and a little help from you guys and .... Bruno  oppps oppps  Kiss Kiss Tongue

can you confirm me these measures?















Bruno I know that you're busy with your gameroom  oppps oppps, but no problem, when you have time.... thanks in advance  Kiss Kiss Kiss

 pacman Ghost    Space Ace Space Ace Space Ace
« Last Edit: January 31, 2009, 11:14:38 AM by DarthNuno » Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
DarthNuno
Administrator
ArcadeLifeStyler'
*****
Posts: 11592


Singe's castle


View Profile WWW
« Reply #1 on: November 25, 2008, 06:37:18 PM »

Yeeeeessssssssss  Smiley You're back with a new project  Kiss

Following your beautiful Galaga Project, I'm sure this Pac-Man scratch build Replica (tm) will kick ass  Cool Kiss

Ok, let me few days for the measures my friend, no problem  Wink
Logged

scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« Reply #2 on: November 25, 2008, 08:28:26 PM »

Great!!! Thank you Bruno  Kiss Kiss Kiss

 Space Ace
Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
DarthNuno
Administrator
ArcadeLifeStyler'
*****
Posts: 11592


Singe's castle


View Profile WWW
« Reply #3 on: November 28, 2008, 03:21:31 PM »

You are lucky, I'm testing my new VAIO laptop and network/wifi/internet access inside my game room. The Pac Man is just behind me, so here we go :

1. Oppss... the picture doesn't really see it, but it's a curve, all the way  Undecided

2. 61 mm

3. 463 mm

4. 840 mm

5. Ouch... it's a curve too, but at the bottom I would say 1712 mm

6. 338 mm

7. 186 mm

8. 1093 mm

9. 7 mm

10. not pictured ?

11. 70 mm

12. 22 mm

13. 80 mm

 Space Ace
Logged

scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« Reply #4 on: November 28, 2008, 04:52:17 PM »

WOOOooooooooooooooooooooooWWWWWW!!!!!



Thanks !!! Thanks !!!! Very fast and accurate like always  Kiss Kiss Space Ace Space Ace

Sorry Bruno, for the first picture (marquee zone) I can say about 3 Cm more or less?

Ok .... as for the Galaga template I should correct some jukobud errors  Twisted Tongue ok no problems ..... let's go  Space Ace Space Ace


Thanks again Bruno !!!!!!

 Kiss Kiss
Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
DarthNuno
Administrator
ArcadeLifeStyler'
*****
Posts: 11592


Singe's castle


View Profile WWW
« Reply #5 on: November 28, 2008, 05:02:06 PM »

No problem  Wink

Ok, regarding the first picture, I would say approx :

35mm from the upper part of the marquee
37mm at the middle of the marquee
45mm at the lowest part of the marquee

Logged

scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« Reply #6 on: November 28, 2008, 07:29:18 PM »

Great Thank you !!!

 pacman
Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« Reply #7 on: November 30, 2008, 04:03:59 PM »

Sorry Bruno, I've a doubt .....  Huh?

the measure N.5 (1712 mm) is from the floor or from the base of the cab?



Thank you  Kiss Kiss
Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
DarthNuno
Administrator
ArcadeLifeStyler'
*****
Posts: 11592


Singe's castle


View Profile WWW
« Reply #8 on: November 30, 2008, 07:08:49 PM »

the measure N.5 (1712 mm) is from the floor or from the base of the cab?


I think it's from the the base of the cab', not from the floor  roll eyes But I'll check tomorrow once again (it's too cold this evening to go outside my house  Roll Eyes TongueGrin
Logged

scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« Reply #9 on: December 01, 2008, 12:38:42 AM »

Ok thanks Bruno  Kiss Kiss,



But I'll check tomorrow once again (it's too cold this evening to go outside my house  Roll Eyes TongueGrin

I can understand you, snow and cold here in northern Italy, I imagine in Belgium  Ghost
Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
DarthNuno
Administrator
ArcadeLifeStyler'
*****
Posts: 11592


Singe's castle


View Profile WWW
« Reply #10 on: December 01, 2008, 05:38:58 PM »

I've just do it again  Cool ... I would say 1712mm from the base of the cab, not from the floor, but once again, I cannot say it's an accurate value because the top is curved and my sizing tool is not easy to manipulate alone for such big measure  oppps
Hope it can help  Undecided
Logged

scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« Reply #11 on: December 01, 2008, 05:53:34 PM »

Perfect!!!  Kiss Kiss

Thanks  Space Ace
Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« Reply #12 on: December 13, 2008, 02:51:37 PM »

.... With new Bruno's measures I can start a new perfect  Kiss template:



Control panel test for right position:




Ok  Kiss Kiss








Ok.. next week will begin the serious work , MDF etc ....   Space Ace Space Ace  Ghost Ghost
Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
amadama
Member
**
Posts: 162


View Profile
« Reply #13 on: December 14, 2008, 05:17:35 AM »

Cool,
The CP placement was actually the toughest part of when I built my Pacman. Best of luck with yours!
Logged
scr33n
ArcadeLifeStyler'
***
Posts: 1674



View Profile
« Reply #14 on: December 14, 2008, 06:06:02 PM »

Yes Amadama you're right (CP zone is difficult  roll eyes I will do my best) and thanks for support  Kiss Kiss

One question: where you bought the sideart and kickplate arts? From Twobit?

Thanks.
Logged

PROJECTS FROM SCRATCH:

Galaga - PacMan - Donkey Kong Red Cab - Track & Field Upright - Tempest - Burgertime - Gyruss - Defender - Track & Field Cocktail - Robotron 2084

RESTORATIONS:

Q*bert - Timber
