« Reply #30 on: January 08, 2021, 08:16:25 PM »

I think, I have some of those, let me check. Wink
Logged
Etienne MacGyver
ArcadeLifeStyler'
***
Posts: 7579


The Netherlands


View Profile
« Reply #31 on: January 10, 2021, 11:38:56 AM »

Hi,

I was shocked to find that these old AMP Italy connectors are actually still in stock:

https://www.digikey.com/en/products/detail/te-connectivity-amp-connectors/280593/1130917

Paul.


Thats very cool, i see also that other sizes are still available.
Next question, i searched for AMP Pin or AMP Connector on the same site, but i cant find the pins that are needed for these, also i never have ordered pins, and know there is a lot of differences.

Do you know which one's go in these ? (preferably a link from that site as they also have a dutch site and ordering will not be a problem i guess)

@ Bela, If you have one, thats also cool ofcourse :-)
Logged
PaulSwan
ArcadeLifeStyler'
***
Posts: 762


ZZZ


View Profile WWW
« Reply #32 on: January 10, 2021, 04:39:52 PM »

The series is called "AMPMODU Mod I" and they have a variety of contacts for the series. This list link *may* work:

https://www.digikey.com/en/products/filter/rectangular-connectors-contacts/331?s=N4IgjCBcoLQCxVAYygMwIYBsDOBTANCAPZQDaIAzABwBMADCALqEAOALlCCAL69A

It appears I've been using 280702-1 "tin contacts" (that I got from Mouser):
https://www.digikey.com/en/products/detail/te-connectivity-amp-connectors/280702-1/1150100

...but there are gold ones as well if you like flash Wink
https://www.digikey.com/en/products/detail/te-connectivity-amp-connectors/280621-1/2263241

Paul.

Logged

ZZZ
Belike
ArcadeLifeStyler'
***
Posts: 4738


Budapest, Hungary


View Profile
« Reply #33 on: January 10, 2021, 07:08:59 PM »

I have 3 pieces of 8 pin connectors, one cut off with very small wires and 2, as a part of a loom.
Also has some crimps. Wink






Logged
Etienne MacGyver
ArcadeLifeStyler'
***
Posts: 7579


The Netherlands


View Profile
« Reply #34 on: January 11, 2021, 02:44:55 PM »

Thanks Paul !

@Bela, Cool, i got a crimper for those pins, so if you can miss one of the connectors and 8 pins (make that 10 if i screw up), i am very interested to buy from you.
Logged
PaulSwan
ArcadeLifeStyler'
***
Posts: 762


ZZZ


View Profile WWW
« Reply #35 on: January 11, 2021, 06:28:41 PM »

Those crimp pins in Bela's photo are not the right pins for the AMP Modu I connector housing, see the DigiKey photo.
https://www.digikey.com/en/products/detail/te-connectivity-amp-connectors/280702-1/1150100
Logged

ZZZ
Belike
ArcadeLifeStyler'
***
Posts: 4738


Budapest, Hungary


View Profile
« Reply #36 on: January 11, 2021, 08:20:33 PM »

Yeah, Paul is right, I tried to install one, but it does not fit to the connector.
The connector with those small wires has all the crimps at each hole factory installed, if you can remove the remaining plastic isolation and solder some cables, it might be ok.
Logged
Digimon
Member
**
Posts: 480


Germany - Hamburg


View Profile
« Reply #37 on: January 11, 2021, 09:40:32 PM »

i have the AmpModu crimp pins.

But I am out of 8pin plugs
Logged

Searching Zaccaria Stuff: Zaxxon CPO, JumpBug CPO or CPO Repro
next project: assemble Zaccaria Vanguard.
Digimon
Member
**
Posts: 480


Germany - Hamburg


View Profile
« Reply #38 on: January 11, 2021, 09:47:46 PM »

you can always get spares in italy:

https://errebishop.com/de/raster-signalsteckverbinder/4329-modu-i-steckverbinder-weiblich-8-wege.html
Logged

Searching Zaccaria Stuff: Zaxxon CPO, JumpBug CPO or CPO Repro
next project: assemble Zaccaria Vanguard.
Etienne MacGyver
ArcadeLifeStyler'
***
Posts: 7579


The Netherlands


View Profile
« Reply #39 on: January 15, 2021, 04:26:06 PM »

Thanks everyone, ill try option from bela first, i think i can solder them on.

Yeah, Paul is right, I tried to install one, but it does not fit to the connector.
The connector with those small wires has all the crimps at each hole factory installed, if you can remove the remaining plastic isolation and solder some cables, it might be ok.
Logged
Laszo
ArcadeLifeStyler'
***
Posts: 986


Building


View Profile
« Reply #40 on: January 19, 2021, 11:57:30 PM »

Conrad also has these connectors,

https://www.conrad.nl/zoeken?search=Amp%20modu&searchType=regular
Logged
